Hints & Suggestions

slides.oddbird.net/hints/btconf/

@ Beyond Tellerand
  • Håkon Lie, 1994
  • email, still archived online
  • not the only proposal for styles on the web
  • not the first
  • solves a major problem for the new platform
  • not technical, but philosophical
  • political, like all decisions we make
  • designing a new platform or interface
  • first web browser
  • Hypermedia WWW Browser and Editor
  • CERN
  • NeXt machine
  • graphic interface

You can’t make a web that’s world-wide, by saying it works on my machine, and everyone else is an edge-case.

  • Nicola Pellow
  • Line Mode browser
  • text-only
  • no install
  • any device with an internet connection
  • includes devices without screen
  • or screen readers
  • read the screen (a combination)
  • If we really want this to work
  • Everywhere for everyone
  • leads to some interesting constraints
  • documented on the original website
  • (still online)
  • browsers ignore code they don’t understand

[DEMO]

  • individual attributes
  • entire HTML tags
  • we can still see
  • first website on modern browsers
  • modern website, on the first browser
  • (this is an emulator you can play with)
  • No css
  • No images
  • all the text is there

Protect the Content

across devices, and over time

  • whatever else happens
  • browsers should protect the content
  • the code is optional
  • the content is essential

It is required that HTML be a common language between all platforms

WWW Project, HTML constraints

  • Which creates a big problem for design specifically
  • For HTML to be a common language everywhere…

…This implies no device-specific markup, or anything which requires control over fonts or colors.

WWW Project, HTML constraints

  • Sir Tim wrote that
  • in 1990 or something
  • He already knew that…

Web Design Will Never Happen

(at least in a graphic sense)

  • The problem isn’t “what” but “how”
  • Early browsers all had built-in stylesheets,
  • Even the text-only browser
  • uppercase headings, space between paragraphs, etc
  • But these styles come from the browser
  • And apply the same to every page on the web
  • All websites look the same

PostScript, 1982 Page Description Language

  • But PostScript around almost a decade
  • giving authors much more control
  • Allowing us to create fully designed documents
  • using only code
  • Describing every aspect of the page in detail
  • and then packaging up the results
  • Like a print designer
  • In control of every detail…
  • We set the page size (static, forever)
  • down to the inks used, and the paper to print on
  • It just sits there
  • We have complete control, but…

The fact we can control a paper page is really a limitation of that medium.

– John Allsopp, A Dao of Web Design

  • That control comes at a cost
  • The page, print or PDF, is a static medium
  • can’t adapt to context or preferences
  • a limitation of the medium

Web Styles Must Be Contextual

  • web is different
  • even static sites aren’t static
  • what we ship is not always what our audience sees
  • styles must adapt to situations…
  • the web is responsive to context
  • Not just the width of the viewport

@media prefers-reduced-motion

  • user needs & preferences
  • device interfaces

@supports container-type: inline-size

  • changing capabilities over time
Animation of twitter-like posts appearing
  • And often unpredictable content
  • Changing all the time
  • All of these variables, because…
  • We’re not alone here
  • We’re part of an ecosystem
  • Our decisions impact other people
  • And on the web, we don’t get final say
  • We’re collaborating with browsers
  • (instructed to ignore us)
  • Also the people who interact with our sites
  • (super cute in their handy tool belts)
  • On their chosen devices
  • (with varying capabilities)
  • And we’re also collaborating with…
  • aliens 👽
  • Maybe, who knows?
  • They’re probably just trying to get home.

Graphic design of unknown content with unknown collaborators, on an infinite and unknowable canvas, across operating systems, interfaces, languages, and writing modes

– me

  • So we’re here, supposed to do…
  • (slide)
  • It’s absurd
  • Under those constraints,
  • design seemed impossible, but…

HTML totally eliminates any visual creativity that a document’s designer might have.

– Roy Smith, www-talk “Re: Adobe’s PDF

  • No one was happy with that outcome
  • When every site looks the same
  • That’s boring for both authors and users
  • Turning point, 1993
  • Mosaic added image tag to HTML
  • Before web standards
  • web styles suddenly possible
  • put everything in an image, and it never changes
  • Just like print design!
  • or it doesn’t show up at all
  • and we lose everything that makes HTML special
  • Can’t protect structured content in an image…
  • If it doesn’t load, it’s lost

The web would have become a giant fax machine where pictures of text would be passed along.

– Håkon Lie, 2014 interview

  • A real risk to the platform
  • (slide)
  • And so we get a rush of proposals
  • around 1993 and 1994
  • trying to save the web from images!
  • It’s time to take HTML to the max!
(HEAD,BODY fontSize=normal
BGColor=white
FGColor=black
(H1 fontSize=largest
BGColor=red
FGColor=white)
(H2 fontSize=large)
(A FGColor=red)
(CMD,KBD,SCREEN,LISTING,EXAMPLE fontFamily=fixed)
(BOLD,EMPH,STRONG fontWeight=bold)
)
  • Pei Wei’s Viola browser
  • Was the first to allow custom style sheets for a page
  • About a year before CSS was proposed
  • It has familiar selectors, nesting, property-value pairs,
  • And even inheritance
  • They all have inheritance, or something like it…

an easily parsable format

@DEFAULT fo(fa=ti,sp=pr,si=14,we=me,sl=ro,fo=in,bo=in,li=no,nu=1,fn='')
ju(st=le,hy=0,ke=0) co(nu=1,wi=80) br(lo=af,ob=it)
li(lo=in,ma=no,li=un,nu=1,be=no,af=no,hi=0)

@UL in(le=5)
@LI ma(pr=ro,be=4) in(le=10,ri=10)
  • Several months before Viola,
  • Robert Raisch proposed this ‘easily parsable format’
  • I assume he means parsable by machines?
  • Because I can’t parse it, I had to memorize the first few lines.
  • You can see the default selector there,
  • We’re setting our default fonts in the fo function
  • Family=times, spacing is proportional, size 14,
  • and then ‘we’ is ‘me’, which…
  • I don’t know,
  • Sounds like a Beatles song?
  • John Lennon had a lot to say about web typography

[Times] is not meant as a font name, per se. Rather it is a suggestion of a particular style of character representation.

– Robert Raisch, Request for comments: STYLESHEETS

  • But Robert is clear that these styles are only suggestions!
  • Even the times font-family
  • doesn’t mean we get the ‘times’ font specifically,
  • it just means we want something like times,
  • a serif font!
  • And he repeats this phrasing…

Styles are suggestions or hints about behavior, not rules

– Robert Raisch, Request for comments: STYLESHEETS

  • Over and over,
  • We’re not writing rules,
  • but suggestions or hints about behavior.

A set of HINTS or SUGGESTIONS to the renderer which might be used

– Robert Raisch, Request for comments: STYLESHEETS

  • Sometimes all-caps
  • hints and suggestions which might not be used.
  • And the other proposals pick this up…

Specified attributes are taken as “hints” that will degrade in a controlled way depending on the level of support… in the operating environment.

– Jon Bosak, Proposal for a language optimized for WWW delivery

  • Jon Bosak’s
  • Hints that will degrade in a controlled way
  • Or, with CHSS
  • We can allow the author to attach style hints

Provide hints that the browser may or may not use.

– Håkon Lie, Cascading HTML style sheets – a proposal

  • Hints that the browser may or may not use

Provide authors and publishers with stylistic influence without resorting to page description languages.

– Håkon Lie, Cascading HTML style sheets – a proposal

  • Authors should have stylistic influence,
  • without resorting to page description languages
  • without giving us full control
  • Use the same resilient logic as HTML
  • browsers ignore css that they don’t understand
  • We don’t get a blank page with an error message,
  • We get the content with default styles.
  • Always protect the content!

Content should be viewable and accessible by default.

W3C, Platform Design Principles

  • This becomes another design principle of the w3c
  • content should be viewable and accessible by default
  • Which is why…
  • The default overflow is visible
  • if we get so cocky
  • that we try to shove large text in a small box
  • The browser will try to bail us out
  • Not because it’s the best-looking solution
  • but because the web is unpredictable
  • and browsers prioritize content over style
  • That’s a good thing!
  • What’s the alternative?
  • InDesign doesn’t even worry about accidental overflow
  • The whole word just disappears!
  • But that’s fine, because we can fix it
  • before we hit print,
  • and it will stay fixed forever
  • Unchanging
  • Unaware of context
  • Unable to adapt
  • By giving up some deign control
  • We allow the web to carry our designs
  • Farther than we could ever go alone
  • Because we’re not alone,

This proposal tries to soften the tension between the author and the reader.

– Håkon Lie, Cascading HTML style sheets – a proposal

  • While CHSS wasn’t the first stylesheet proposal,
  • It didn’t invent selectors, or properties, or even inheritance
  • It was the first to suggest an equal collaboration
  • Designed to soften the tension
  • Between the author and the reader

While the author (or publisher) often wants to give the documents a distinct look and feel, the user will set preferences to make all documents appear more similar.

– Håkon Lie, Cascading HTML style sheets – a proposal

  • Authors want to show their creativity and branding,
  • with a distinct look and feel,
  • make their document visually interesting.
  • But users will have preferences,
  • styles that they like better (or even require)
  • like larger text or dark mode,
  • and sites can respect those preferences!

The proposed scheme is balanced in the sense that it provides author and reader with the same notation for specifying style.

– Håkon Lie, Cascading HTML style sheets – a proposal

  • We do that by allowing everyone to contribute styles
  • Written in the same language
/* a 'declaration' */
property: value;
color: blue;
  • Each of us providing
  • our style hints as declarations,
  • a property and a value
/* a selector, with attached declarations… */
/* a 'style rule' (or 'rule set') */
p {
background: white;
color: mediumVioletRed;
}
  • We can group those together,
  • and add selectors
  • forming rule-sets…
<!-- a 'style sheet' -->
<link rel="stylesheet" href="styles.css">
  • Which can be attached to an HTML document,
/* another 'style sheet' */
@import url('styles.css');
  • Or chain together,
  • Resulting in…
  • An ordered list (or ‘cascade’) of stylesheets
  • all applied to the same web site,
  • But not coordinated…
  • Remember, anyone can add styles to the page
  • So, of course, this leads to conflicts!…
/* <button type="submit" id="send" class="action"> */
button { background: gray; }
.action { background: darkBlue; }
[type=“submit”] { background: darkGreen;
background: var(--submit, black); }
#send { background: maroon; }
  • We have any number of declarations
  • coming from different sources
  • likely applying different values
  • to the same properties, on the same elements!

For Browsers Every CSS Property
On Every HTML Element,
Must Have a Single Value

  • Browsers need to resolve conflicts.
  • Every CSS property
  • on every HTML element
  • must have a single value

Every <button> Needs One Background-Color
& One Text Color
& One Padding-Left
& One Margin-Inline-End
&

  • Every button needs
  • one text color,
  • one padding-left,
  • one margin-inline-end, etc.
  • To get there, we need…
Tina Turner as Aunty Entity in the Mad Max Thunderdome, with the law 'Two styles enter, one style leaves' in bold text
  • Some way to thunder-dome our declarations
  • And choose a single winner
  • Two styles enter, one style leaves
/* button { background: gray; } */
/* .action { background: darkBlue; } */
[type=“submit”] {
/* background: darkGreen; */
/* background: var(--submit, black); */
}
#send { background: maroon; }
  • The simplest way to choose a winner,
  • We can let each declaration override the previous one
  • Until there’s only one left
  • Last takes precedence
  • We’ll start there, but…
  • Someone has to go first,
  • And who gets to go last?
  • We have to put everyone into some kind of order

First… 🖥 User Agent Styles

  • Sure, ok.
  • We can start with the styles we already have
  • At the bottom of our cascade,
  • first and least important
  • The browser, or user agent
  • providing legible defaults
  • That’s essential!
  • You can’t render text without styling it somehow!
  • This email archive doesn’t add any document styles,
  • But the browser is providing some!
  • Let’s see what happens when we remove those.
  • [demo]
  • * { all: initial; }
/* initial values */
display: inline;
background: transparent;
color: CanvasText;
font-style: normal;
flex-basis: auto;
/* etc. */
  • Here we’re seeing initial values
  • The specification defines
  • An initial value for each property
  • Display inline, background transparent, and so on
body { display: initial; } /* inline */
section { display: initial; } /* inline */
div { display: initial; } /* inline */
span { display: initial; } /* inline */
head { display: initial; } /* inline */
title { display: initial; } /* inline */
  • The initial value for display
  • is always inline!
  • Doesn’t matter what element we’re talking about
  • Body, section, div, span…
  • Even something hidden like the head or title element
  • Would get display:inline by default
  • If the browser didn’t come along and set…
html, body, p, div, article, aside, header,
hgroup, footer, main, nav, section /* etc */ {
display: block;
}

base, basefont, datalist, head, link, meta,
script, style, template, title /* etc */ {
display: none;
}
  • display:block and display:none
  • everywhere we expect it
body { margin: 8px; }
a:link {
color: blue;
text-decoration: underline; }
h1, h2, h3, h4 /* etc */ {
font-weight: bold;
font-size: something big I dunno; }
  • They also add things like
  • 8px margin on the body
  • Link colors and underlines
  • Heading styles, large bold text
  • Space around paragraphs and lists, etc
  • These are the user agent styles
  • And they apply to every site on the web
  • With only minor differences between browsers

Second… 👥 User Styles

  • After browser defaults
  • Users apply their preferences

[CSS] provides author and reader with the same notation

– Håkon Lie, Cascading HTML style sheets – a proposal

  • Originally using CSS syntax as well
Safari settings panel, advanced tab, with a red scribble highlighting a style sheet option, with none selected by default.
  • Safari still supports this option
  • In the settings panel, upload a stylesheet
  • Other browsers have mostly switched
  • To limited preference settings in a graphic interface
  • Safari/WebKit:
    Settings / Advanced / Style sheet…
  • Firefox/Gecko:
    about:preferences
  • Chrome/Blink:
    chrome://settings/appearance
  • The details are different
  • But the results are the same
  • Users get to set some default preferences
  • That are applied to every site they visit
  • And to be clear,
  • When we talk about ‘users’ or ‘readers’
  • on the web…

We All Use The Web

More than we author it

  • We’re talking about all of us
  • We all use the web
  • And I think it’s safe to say
  • We spend more time using the web
  • Than we spend building it
  • And we’re all allowed to have preferences!
  • Not just light mode or dark mode,
  • But fonts, font sizes, all of it.

Go ahead… Make The Web Your Own

  • I used to worry as a dev - “but I’ll see something different than the user” - That’s the point! People might see something different! - Having a unique setting is a great way to remember that

Finally… 🎨 Author Styles

from the author origin

  • Finally, ‘document’ or ‘author’ styles
  • (also us, making stuff for the web)
  • We come last

🗺 Cascade Origins

  1. 🖥 User Agent Defaults (first, lowest priority)
  2. 👥 User Preferences
  3. 🎨 Author Styles (last, too powerful)
  • And so we get the highest priority,
  • Last takes precedence, remember!
  • These are called the ‘cascade origins’
  • We override the user preferences
  • Which override the browser defaults
  • Which is a lot of power for us to have!
  • Sometimes we’re not even paying attention
  • Or we throw a fit…
  • And stomp around force-choking everyone in our way
  • But Håkon was clear…

If conflicts arise the user should have the last word

– Håkon Lie, Cascading HTML style sheets – a proposal

  • When it really matters,
  • The user should have the last word

If a trade-off needs to be made, always put user needs above all.

W3C Web Platform Design Principles

  • This has also become a W3C principle
  • Always put user needs above all
  • So the original proposal included
  • A percentage next to each declaration
  • Expressing how important that style is
/* user styles */
html { background: blue 64%; }

/* site styles */
html { background: red 100%; } /* only 36% */
  • And if the user requests 64% control,
  • It doesn’t matter how much we want,
  • This isn’t winner-takes-all,
  • It’s first-come-first-served
  • And there’s only 36% remaining influence for us…
  • And the result is a weighted average of our styles!
  • I wanted blue, but you asked for red,
  • So here’s the purple no one asked for!
  • People immediately pointed out how this could go wrong
  • And how hard it would be to average other values like fonts
  • Although I wish we had tried harder on that one
:      User            Author
Font o-----x--------------o 64%
Color o-x------------------o 90%
Margin o-------------x------o 37%
Volume o---------x----------o 50%
  • I honestly love this final diagram that Håkon provides
  • ASCII art of a graphic interface with range sliders
  • So users can fine-tune their design
  • Live-mixing the relative weights of every declaration
html { background: blue; }            /* 0%   */
html { background: red !important; } /* 100% */
  • It was simplified into a binary option
  • 0% by default, or 100% with the important flag…
  1. 🖥 User Agent Defaults
  2. 👥 User Preferences
  3. 🎨 Author Styles
  4. ❗🎨 Author Important
  5. ❗👥 User Important
  6. ❗🖥 User Agent Important
  • Important styles generate three new origins!
  • They always win over normal styles,
  • But now we go in reverse order
  • Authors first, but then user preferences
  • And the browser plays cleanup
  • It’s a mirror universe where
  • All our evil twins have goatees
  • Yes, browsers defaults are often important
In the font preferences dialogue, a default-checked option: Allow pages to choose their own fonts, instead of your selections above
  • And users can set important styles
  • Using CSS in Safari
  • Or a checkbox in the Firefox settings
  • Importance doesn’t change specificity
  • It changes the origins
  • And the priority of origins
  • The purpose…

Authors 👎🏼 Specificity Wars

With our own colleagues and libraries

  • Is not for fighting each other
  • In big teams who can’t agree
  • Or angrily trying to override
  • Styles we wrote last year

Browsers/Users 👍🏼 Protect Styles

From higher origins breaking important things

  • The purpose is for users and browsers
  • To protect style from future origins
  • Someone that might come along later…
  • That’s us
  • Importance exists to
  • protect our users from what we might do!

Often Isolated

  1. 🎨 Author Styles
  2. ❗🎨 Author Important
  3. ❗…
  4. ❗…
  • But the way our origins (normal and important)
  • Are isolated together…
  • We start to think
  • We’re the center of the universe
  • When we’re really just one pale blue dot
  • In the solar system of the cascade
  • Which rotates around user needs!
  • Fair, it’s what we deal with every day
  • But we need to have perspective
Headshot of Yoda (basically)

A Jedi uses the [Cascade] for knowledge and defense, never for attack.

– Yoda (basically)

Graphic design of unknown content with unknown collaborators, on an infinite and unknowable canvas, across operating systems, interfaces, languages, and writing modes

– me

  • So now we’re not just dealing with
  • some extreme unknowns
  • Infinite diversity in infinite combinations

There are too many variables to consider. The point of CSS is to make it so you don’t have to worry about them all.

– Keith J Grant

  • But the browser is allowed to ignore us
  • And the user can override anything we say
  • There are two many variables,
  • and everything we say is a suggestion…

The point of CSS is to make it so you don’t have to worry about them all.

– Keith J Grant

  • But everything we say is also a hint
  • Telling the browser something about our intent
  • CSS is a declarative language
  • Some declarations seem simple,
  • the width of a box
  • While some are more abstract,
  • wrapping text so it looks ‘pretty’
  • (whatever that means)
  • But even ‘simple’ declarations contain subtext
  • What do we mean by a pixel?
  • Should this box get smaller on a screen with higher resolution?
  • How should it respond to zooming in and out?
  • Are we setting the width of the content box?
  • (so padding and border are added to our width)
  • Or the width of the entire box,
  • so padding and border are subtracted to get the content size?
  • Should it be based on context
  • a parent element, viewport, or container
  • Or flexible in relation to sibling elements
  • And remaining space
  • Or should we stop looking sideways,
  • and look within
  • To get the size of the contents
  • That’s a great suggestion, Jessica
  • Maybe it’s not the width we care about at all,
  • that’s just the direction text flows.
  • Are we trying to set the length of a line of text?
  • Should it be based on the size of the font?
  • Or some combination
  • Like the minimum, of two values
  • Everything in CSS based on
  • constant back-and-forth
  • context pushing in,
  • (defining available space)
  • content pushing out
  • (taking up space)
  • How do we ensure
  • Our content will fit
  • any container we put it in?
  • We don’t have all the information, but the browser does
  • So the most useful tools in CSS
  • express this kind of abstract behavior
  • let the browser work out details
  • Like all design choices
  • Our styles are contextual
  • Properties often behave differently
  • or not at all, depending on other properties
  • As a result, CSS features tend to be intertwined
  • Behavior is never isolated,
  • And everything has side-effects
  • We’re not doing functional programming,
  • What we do is more expressive, like poetry
  • Not describing the page in step-by-step detail
  • but communicating high-level ideas through subtext
  • Not just the result we want
  • But the intent behind each choice
  • Units are great at this
  • (it’s why CSS has so many of them)
  • On the surface 1em is sometimes 16px
  • But they carry different implications
  • And adapt differently in context
  • Similar with layout methods
  • We can sometimes get the same result
  • using either flexbox or grid
  • But they move differently at the edges,
  • And our job, the entire reason we’re here
  • Is not to make things look good on one device,
  • Or in a single browser, but…

The fact we can control a paper page is really a limitation of that medium.

– John Allsopp, A Dao of Web Design

  • By letting go of control…

Provide hints that the browser may or may not use.

– Håkon Lie, Cascading HTML style sheets – a proposal

  • While expressing ourselves clearly
  • Providing hints and suggestions
  • We can express what we want
  • To the browser
  • Like a therapy robot
  • So it can help us adapt
  • When incidents inevitably happen
  • Because incidents always happen

To me, this meme perfectly captures what is actually awesome about CSS – and how we can go wrong by taking too much control without considering the consequences. So how can we lighten our grip here?

[demo] change to use intrinsic sizes

  • We’re not alone on this platform
  • and everything about CSS
  • is built around that political vision
  • Respect the user

It takes craft to set up the circumstances that are simple and yet contain the ambiguities and the incongruity of human experience.

– Anne Bogart

  • This is our job as designers, design engineers
  • Not forcing everyone into a singular experience
  • But setting up the circumstances for communication
  • In an unpredictable world,
  • adapting to the incongruities of human experience

Content should be viewable and accessible by default.

W3C, Platform Design Principles

  • Protect the content
  • Do no harm
